How to make an appliance for collecting apples with your own hands
When it's time to collect fruits from hightrees, the most beautiful and ripe are so high that even with the help of a ladder they can not be reached. Of course, in doing so, you can use a long stick with which to knock the fruit. Some gardeners shake the trees, but the apples are damaged and lose their attractive appearance. As an alternative, you can use a device for collecting apples. If it is not at hand, and the purchase does not want to spend money, then you can make such a tool yourself in a short time. As a result, it will be possible to obtain a fruit picker, which will not differ in efficiency of use from what is produced in the plant conditions.
Selection of design features before manufacturing
If we consider the fruit pickers, then they can bedivided into several groups. The first of these is a tool that is equipped at the end of the bar with cutters. With the help of this supplement it is possible to cut the peduncle and the apple will fall into the container, which is located in the immediate vicinity of the cutter. Such a device for collecting apples has a movable knife, which is activated by means of special traction. To work with such a device is quite tiring, as the cutter is located on the rod, or rather, on its long shoulder. This creates an extra weight, which is very decent. The device for collecting apples can refer to the second group, the instruments of which resemble a mechanical hand equipped with fingers. The latter are made of wire. After the apple or pear is caught with the help of special fingers, the latter are clamped by traction, and the fruit is in the container. This action is performed using traditional twine. This is what allows you to tear off the fruit. As a minus of the given tool it is possible to allocate that together with a pear or an apple the branch itself can break off.
The third group of fruit pickers
If you make a devicefor collecting apples, it is possible to take as a basis the third group, which is the most common for design features. Such constructions are made of elastic light plastic or fabric. And the shape of the product is a bowl, equipped with petals. A special container must be attached to a wooden pole. Apples are removed simply by turning the pole around an axis that is oriented along. The leg is then trimmed by means of the petals of the instrument.
Preparing for the production of a fruit picker
Apparatus for collecting apples from a tree mustOnly after you have chosen one of the suggested ideas. The third version will form the basis of the simplified construction of the tool for fruit assembly. First you need to prepare a plastic bottle. If you are going to collect quite impressive fruits in size, then the capacity of the container is within 2 liters, whereas for medium-sized apples or pears a bottle with a volume limited to 1.5 liters is suitable. Every summer resident certainly will have such bottles.
If you carry out the device forcollecting apples by hand, then the bottle should be cut off the bottom, and then make a corner cutout. Use this will be convenient as a knife, and scissors. The above-described cut along the bottle can also be made on the opposite side.
After the cup has been prepared, it is necessaryattach to the pole, the last of which can be a long light rake. Fixation can be carried out with the help of a wire or a self-adhesive adhesive tape. After that, we can assume that the fruit picker is ready for operation. To use it, the tool must be brought from below the pear or apple, and then rotated around the axis. This will cut the stem of the fetus with a cutout that is located on the instrument. The apple will be in the bottle, which at the same time is capable of performing the role of a collection tank and a cutter function. A similar device for collecting apples from a plastic bottle can be used without lowering the container for some time. In one bottle can fit a few fruits.
Making a fruit picker from a bottle and fishing line
Before making a collection deviceapples, you need to decide on the design features of the future tool. The basis can lie still the same plastic bottle, a handle from a mop, which is sometimes replaced by a PVC pipe or a ski pole, as well as a fishing line. The length of the latter can vary between 2.5 and 3 meters. You will need scissors and an awl.
To begin with, it will be necessary to produce the so-calledIt was enough, which is carried out from a plastic bottle. The bottom of the container should be cut in such a way that a crown resembles a shape. In each petal, two holes are made, for this you can use an awl or hole punch. In the next step, the product should be given tenacity. To do this, a fishing line is used, which is pulled through the neck into the container in such a way that its upper end passes through each hole in a circle. Lead the line back through the neck. This will get a bottle that has no bottom. Two long ends will come out through the neck.
The next stage is to fixholder, in whose role a full PVC pipe should be used. Double line from the bottle must be passed through the hole of the holder, removing from the back side. If the squeegee handle has a removable handle, then this is a good solution. To this part of the holder it is necessary to fix the ends of the line. In the handle, two holes are made, into which the line is cut, the ends are fixed on the other side in a pull. The handle is then again put on the handle. If you are making arrangements for the collection of pears and apples, it is important to assemble the entire structure in such a way that the plastic bottle is tightly attached to the holder. Cropped edges of the bottle bend. At the same time you need to make grabbing movements. This is the principle of collecting fruits with this tool. If the squeegee is devoid of a removable part, then its end must be eliminated, then it should retreat 10 cm. On the sides, you need to make two holes where the ends of the line are passed. After they need to fix among themselves, and then bind.
Recommendations of an experienced summer resident
For a PVC pipe as a handle, you can applya few bottle caps. If you use ten covers, having done in the central part of each hole with an awl, then the free ends of the line can be passed through the caps, fixing them on the last. For the stability of the lids, you need to glue them together or make a knot by placing it on the inside of the first lid. This will make it possible to get a fairly convenient removable handle made of caps. In this case, it is necessary to use the same technology as in the case of a squeegee handle.
If you decide to make a device forcollecting apples from the ground, then you can use one of the technologies described above. However, it may be necessary to place the bottle not along the stick-holder, but at a certain angle. This will allow you to collect up to four apples in one container, depending on the size, and then pour out their bucket. One of the listed devices is simple enough to make independently. For this, you do not even have to visit the store in order to purchase materials.
